Meeting Room Office Divider Walls Office Partitions Panels Fabric

Meeting Room Office Divider Walls Office Partitions Panels Fabric

Szczegóły Produktu:

Place of Origin: China
Nazwa handlowa: BUNGE
Model Number: Type 65

Zapłata:

Minimum Order Quantity: 10 Square Meters
Cena: US $ 100 - 300 / Square Meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face
Delivery Time: 10 working days after received your payment
Payment Terms: T/T
Supply Ability: 5,000 Square Meters per Month
Najlepsza cena Kontakt

Szczegóły informacji

Track: Aluminum Surface: Fabric
Thickness: 65mm Sound Proof: 32 / 38 dB
Weight kg/m2: 22 / 30 Max Panel Height mm: 4000
High Light:

office workstation partition

,

modular office workstation

opis produktu

Meeting Room Office Divider Walls Office Partitions Panels Fabric



 Office Partition Wall, Movable Wall for Restruant Functuin Hall Meeting Room



Bunge aluminium movable partition wall and operable partition wall acoustic movable partition for convention & exhibition centre ( used office room dividers , wood partition , movable wall , restaurant partitions , soundproof folding partition , moveable partition , wall partition , living room partition wall, sandwich panel price, accordion wall , economic partition walls , folding wall, foldable partition wall, folding partition wall , movable sound proof partition , removable wall partition , folding partition , removable partition , partition, partition wall, room divider , room dividing partition , office partition , folding partition wall panel , folding wall panel , folding wall systems )





Specifications:



Technical Parameter for Partition Panel

Panel Width

23 - 48 inch

Panel height

78 - 156mm

Sound proof

32 - 38 dB

Operation

Manual

Frame

Aluminium

Vertical profile

Anodised aluminium profiles with integrated magnetic strip and sealing edges on the inside

Finish options

Fabric, veneer, HPL melamine, vinyl, carpet, customers own material, Bare finish

Base options

Plywood, Gypsum, steel, MDF

Max width

Unlimited

Panel weight

25 - 40 kg / sq

Pass door selection

door

Single dor or double door

Seals

Top

Manual

bottom

Manual





Why choose us?


1. Most of our products are customized as your requirement;
2. Free design, we could offer you solution as your budget
3. One stop building material supply with kitchen cabinet, wardrobe, aluminum window&door, timber door, stair&balustrade, shower, etc to save your time, energy and cost
4. One stop service, besides design, production, we could also arrange shipping for you;
5. We have professional team for each market to offer better and more prompt service;
6. We have rich project experience and very familiar to their building code;
7. All of our goods have two years warranty;





Applications :

1. Change the room space freely dividly.
2. Heavy Track loading capacity make sure the safety of Partition .
3. Precise welding between separate rail can eliminate repairing and maintenance rate .
4. Partition retract and push easily for one people to handle the operating work .
5. Wide application: can be used in Office place , commercial place , exhibition place , Hospital place .



Easy Parking On Movable And Operable Partition System

In their stacked position , the elements form a compact package and can be accommodated in the smallest of spaces depending on the room situation . The low weight of the elements and the associated structural advantages are particularly noticeable here.The four standard stacking or parking track systems offer convenient operability with a minimum of noise from the individual elements as they slide into position on movable and operable partition system .


The partitions may be finished with a selection from our standard un-finished MDF or un-finished plywood board (included in the price) or with optional fabric  , leather , melamine , high pressure laminate, murals, or other custom surfaces . And pass through door or glass window can be apply additionally.




Operation :

Partitions shall be top supported, manually operated panels stacked in an area nominated in the plans. When closed, the operable wall shall provide a complete sound retardant barrier. No floor track shall be used.





Track :



The tracks are made from extruded 6063 – T6 anodized aluminum . The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections , and shall be reinforced overhead by drop rod brackets . Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track .



Trolley



BUNGE Centre / Side / Remote stacking system with a Two wheeled nylon trolley made with the base Material of POM 45 tempered steel shall be used as per approved stacking method .
